| Max working wood door size | 2300*1000*70mm |
| Max wood door thickness | 70mm |
| Max hinge groove length | 200mm |
| Max hinge groove width | 55mm |
| Max hinge groove depth | 15mm |
| Milling speed | 18000 rpm |
| Milling blade quantity and motor power | 1.2kw*3 |
| Vertical lifting workingtable motor | 0.75kw*1 |
| Horizal workingtable motor | X.Y shaft 0.75kw*2 |
| Vertical workingtable motor | Zshaft 1.3kw |
| Over dimensions | 2500*1400*950mm |
| Net weight | 680Kg |
